by Christian Alexander Steinle (Author)
In view of the very heavy CBM experiment constraints on the first level trigger, no conventional trigger is obviously applicable. Hence a fast trigger algorithm with the goal of realization in reconfigurable hardware had to be developed to fulfil all requirements of the experiment. In this connection the general Hough transform, which is already utilized in several other experiments, is used as a basis. This approach constitutes further a global method for tracking, which transforms all particle interaction points with the detector stations by means of a defined formula into a parameter space corresponding to the momentum of the particle tracks. This formula is of course developed especially for the given environment of CBM and defines thus the core of the applied three dimensional Hough transform. As the main focus of attention is furthermore on the realization of the needed data throughput, the necessary complex formula calculations give reason to outsource predefined formula results in look-up tables. This circumstance offers then collaterally the possibility to utilize any other sufficiently precise method like Runge-Kutta of fourth order for example to compute these look-up tables, because this computation can be evidently done offline without any effect on the Hough transform's processing speed. For algorithm simulation purposes the CBMROOT framework provides the module 'htrack', which is written in the programming language C++. This module includes many analyses for the determination of algorithm parameters, which can be even executed automatically to some extent. In addition to this, there are of course also analyses for the measurement of the algorithm's quality as well as for the individual rating of each partial step of the algorithm. Consequently the milestone of a customizable level one tracking algorithm, which can be used without any specific knowledge, is now obtained. Besides this, the investigated concepts are explicitly considered in the implement
Author Biography
Christian Steinle, born on February the 8th 1979 in Heidelberg, Germany, grew up in the small town Kirrlach in Baden. Although his interests concentrated in sports at a younger age, they were directed to applied sciences in consequence of many injuries. He thus determined decided to acquire the academic degree doctor of natural science after his university studies in computer engineering. As he felt the fascination for the development of hardware already during his studies, which resulted evidently in increasing special knowledge and skills in many fields of study, he opted for a challenging project in high-energy physics, which certainly means developing or applying specialty hardware. In this connection, it became apparent that his studies in business administration count definitely also in scientific research. This gained knowledge qualified the author afterwards for his job at the company Unicon Software GmbH, which is located in Karlsruhe, Germany.
