Additional information
by Ascent -. Center for Technical Knowledge (Author)
Note: This book is a continuation of AutoCAD 2019: Fundamentals (Mixed Units) - Part 1.
The AutoCAD(R) 2019: Fundamentals learning guide is designed for those using AutoCAD(R) 2019 with a Windows operating system. This learning guide is not designed for the AutoCAD for Mac software.
The objective of AutoCAD 2019: Fundamentals is to enable you to create, modify, and work with a 2D drawing in the AutoCAD software.
Part 1 (chapters 1 to 20) covers the essential core topics for working with the AutoCAD software. The guide begins with learning the basic tools for creating and editing 2D drawings. It then continues to explore the tools used to annotate drawings by adding text, hatching, dimensions, and tables. More advanced tools, such as working with blocks and setting up layouts, are introduced to improve your efficiency with the software. Not every command or option is covered, because the intent is to show the essential tools and concepts, such as:
- Understanding the AutoCAD workspace and user interface.
- Using basic drawing, editing, and viewing tools.
- Organizing drawing objects on layers.
- Using reusable symbols (blocks).
- Preparing a layout to be plotted.
- Adding text, hatching, and dimensions.
Part 2 (chapters 21 to 32) continues with more sophisticated techniques that extend your mastery of the software. For example, here you go beyond the basic skill of using a template to understand the process of setting up a template, creating annotation styles, and how to work with external references. You learn such skills as:
- Using more advanced editing and construction techniques.
- Adding parametric constraints to objects.
- Creating local and global blocks.
- Setting up layers, styles, and templates.
- Attaching External References.
Prerequisites
- Access to the 2019 version of the software. The practices and files included with this guide might not be compatible with prior versions.
- A working knowledge of basic design/drafting procedures and terminology.
- A working knowledge of your operating system.
Author Biography
ASCENT develops and produces a wide range of courseware offerings, knowledge products, and courseware for the industry's leading engineering software tools from Autodesk, Dassault Systèmes, and PTC. ASCENT's team is comprised of courseware developers, engineers, instructional designers, architects, and technical writers who work together to create training solutions that work for our clients. Our curriculum group specializes in the creation of blended education programs that incorporate the best of expert-led and technology-based training offerings to create the most effective course content and ensure that users achieve maximum productivity from their chosen engineering tools. We also work to meet our client's needs by offering different levels of customization for classroom-training curriculum.
