by Merrick Vane (Author)
Most CAD tutorials show you a finished model and briefly summarize the clicks required to get there. You watch the video, try it on your own canvas, and immediately hit a wall when a sketch refuses to constrain or a mechanical joint moves the wrong direction.
This CAD Project Workbook was written to solve that exact frustration. You do not read pages of abstract theory. You open the software and immediately start sketching. The book guides you through actual part modeling, assembling multiple components, and generating professional 2D blueprints. You learn a command only because you physically need it to finish the geometry on your screen.
The exercises mirror the actual friction of mechanical design. Instead of getting bogged down in endless menus, you will design solid parts like a manifold flange and add structural ribs. You will assemble components using constraints and pins so they interact correctly in the digital workspace. When your 3D models are complete, you will transition to the drafting environment to place projected views and add exact dimensions for manufacturing.
You never have to guess what to practice next. The sequence builds naturally from basic shapes into complex solid bodies and full assemblies. When you finish the final drawing, you will possess the muscle memory to look at a physical object on your desk and know exactly which commands will recreate it on your screen.
