Additional information
by Ascent -. Center for Technical Knowledge (Author)
The main purpose of the Autodesk(R) Revit(R) Architecture software is to design buildings: walls, doors, floors, roofs, and stairs. However, architects also frequently need to add site and structural information. The Autodesk(R) Revit(R) 2019 Architecture: Site and Structural Design guide covers the elements and tools that are used to create topographic surfaces for site work and add structural elements.
Site Topics Covered
- Create topographic surfaces
- Add property lines and building pads
- Modify toposurfaces with subregions, splitting surfaces and grading the regions
- Annotate site plans and add site components
- Work with Shared Coordinates
Structural Topics Covered
- Create structural grids and add columns
- Add foundation walls and footings
- Add beams and beam systems
- Create framing elevations and add braces
Prerequisites
- Access to the 2019 version of the software. The practices and files included with this guide might not be compatible with prior versions.
- Users who purchase this learning guide should be comfortable with the fundamentals of the Autodesk Revit Architecture software as taught in the Autodesk(R) Revit(R) 2019: Fundamentals for Architecture guide, and have knowledge of the basic techniques taught in this guide.
- Information on the Autodesk(R) Revit(R) Structure software, which is optimized for structural engineering, is covered in a separate guide.
Number of Pages: 118
Dimensions: 0.25 x 9.25 x 7.5 IN
Publication Date: March 27, 2019
