Additional information
by Ascent -. Center for Technical Knowledge (Author)
The Autodesk(R) Revit(R) software is a powerful Building Information Modeling (BIM) program that works the way architects think. The program streamlines the design process through the use of a central 3D model, where changes made in one view update across all views and on the printable sheets.
The objective of the Autodesk(R) Revit(R) 2020: Fundamentals for Architecture guide is to enable you to create a full 3D architectural project model including walls, doors, windows, components, floors, ceilings, roofs, stairs, the basic tools that the majority of architectural users need. This includes how to navigate the user interface and use the basic drawing, editing, and viewing tools. The final part of the course focuses on creating construction documents.
Topics Covered
- Understanding the purpose of BIM and how it is applied in the Autodesk Revit software.
- Navigating the Autodesk Revit workspace and interface.
- Working with the basic sketching and modifying tools.
- Linking CAD and Revit files as the basis of a project.
- Creating Levels and Grids as datum elements for the model.
- Creating a 3D building model with walls, curtain walls, windows, and doors.
- Adding component features, such as furniture and equipment.
- Adding floors, ceilings, and roofs to the building model.
- Modeling stairs, railings, and ramps.
- Setting up sheets for plotting with text, dimensions, details, tags, and schedules.
- Creating details.
Prerequisites
- Access to the 2020 version of the software. The practices and files included with this guide might not be compatible with prior versions.
- An understanding of architectural terminology is an asset.
