Additional information
by Ascent - Center for Technical Knowledge (Author)
This guide will provide an introduction to the Autodesk(R) Vehicle Tracking module that can be added to Autodesk(R) Civil 3D(R), as well as to the AutoCAD(R) and AutoCAD(R) Architecture software. The Vehicle Tracking module is an extensive transportation analysis and design solution for vehicles of all sorts. This software also features specialized tools for parking lot layout and roundabout design.
Topics Covered
- Navigate through the Vehicle Tracking user interface.
- Use the Vehicle Library.
- Create and edit paths using options such as Arc mode, Bearing mode, or Guided Paths.
- Run Vertical Clearance to check for clash locations.
- Use Design Checks to further analyze the design.
- Create animations of navigating through a chosen path.
- Create and edit parking lots using various row options.
- Create and edit roundabouts with and without corridor functionality.
Prerequisites
- Access to the 2021.0 version of the software, to ensure compatibility with this guide. Future software updates that are released by Autodesk may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (e.g., 2020).
Number of Pages: 194
Dimensions: 0.41 x 9.25 x 7.5 IN
Publication Date: November 06, 2020
