The CATIA V5-6R2017: Advanced Part Design learning guide is ideal for experienced CATIA users who want to extend their modeling abilities with advanced functionality and techniques. This extensive hands-on guide contains numerous projects focused on process-based exercises to give students practical experience while improving design productivity. Students will learn techniques for reusing data, tackling complex geometry, using wireframe, working through feature failure, and investigating the model with analysis tools.
Topics Covered
- Effective modeling practices and design methodology review
- Advanced multi-section solid and rib/slot operations
- Advanced draft and fillet creation and troubleshooting techniques
- Advanced patterning techniques and user patterns
- PowerCopy creation and instantiation
- Design tables
- Catalog creation
- Creating and managing multi-model links
- Multi-body modeling techniques
- Performing Boolean operations
- Knowledge Templates
- Wireframe Lines and Curves
- Analysis Tools
- Feature Failure Resolution
- Thickness, Remove Face and Replace Face features
- Introduction to Automation
- Project Exercises
