Additional information
by Ascent -. Center for Technical Knowledge (Author)
The CATIA V5-6R2017: Introduction for Managers and Reviewers learning guide introduces you to the interface and analysis capabilities of CATIA V5. This guide, with numerous practice exercises, focuses on the concepts of measurement, analysis, image capture, and drawing creation.
Topics Covered
- Overview of Parametric Design Process
- Customization of CATIA V5 Environment
- Feature Management Using the Hide/Show, Activate/Deactivate Functions
- Obtaining Part Information
- Assembly Design Workbench and assembly creation techniques
- Performing measurements and clash analyses
- Creating and viewing cross sections
- Creating and managing annotations
- Image raptures
- Working with cache
- Creating scenes
- Drawing view creation
- Creating and Constraining Sketch Geometry
- Adding Material with Pad and Shaft Features
- Removing Material with Pocket and Groove Features
Prerequisites
- Access to the CATIA V5-6R2017 software. The practices and files included with this guide might not be compatible with prior versions.
Number of Pages: 450
Dimensions: 0.91 x 9.25 x 7.5 IN
Publication Date: January 06, 2020
