Additional information
by Department of Health and Human Services (Created by), National Institute for Occupational Safe (Created by)
The National Mining Association and the Mine Safety and Health Administration requested that the National Institute for Occupational Safety and Health (NIOSH) conduct full-scale evaluations of a recently developed carbon fiber-reinforced polymer (CFRP) reinforcement technique for upgrading existing mine ventilation seals to withstand an explosion pressure of 50 psi or greater. The evaluation was conducted in the NIOSH Pittsburgh Research Laboratory Lake Lynn Experimental Mine (LLEM) near Fairchance, PA. The purpose of the evaluation was to determine the blast resistance of the CFRP reinforcement technique, designed to increase the strength of two types of existing 20-psi-rated in situ mine ventilation seals. Two candidate ventilation seals were selected to represent the 20-psi alternative seal designs typical of those used in mines prior to July 2006. Installed within the LLEM were (1) a 4-ft-thick pumpable cementitious foam seal using material with a designed 150- to 200-psi average compressive strength at 28 days and (2) a 24-in-thick, low-density cementitious block seal with a center pilaster and keyed to the floor and ribs. The materials necessary for the CFRP reinforcement technique were then installed on the outby (active) side of each seal, and the seals were subjected to explosion overpressures. Both seals with the CFRP reinforcement retrofit successfully withstood explosion pressures of 60 psi or greater during the full-scale evaluations in the LLEM.
