by Brian Schwab (Illustrator), Steven Ghazi (Author)
This comprehensive and easy-to-follow guide is a valuable resource for diagnosing and troubleshooting the electrical systems of the 2013 Ford F-150. Whether you're performing basic maintenance or addressing complex electrical issues, this manual offers clear and detailed information to support efficient diagnostics and repair.
- Electronic Control Units (ECUs) and modules are represented through simplified digital logic diagrams, illustrating software and electronic control functions.
- Electrical signal paths are shown from origin to termination, integrating both software and hardware logic for clarity.
- Includes over 300 CAN-Bus messages, with each message source and destination clearly identified.
- Equipment package diagrams are provided for the 2013 F-150 XL, STX, XLT, FX2/FX4, Lariat, King Ranch(R), Platinum, SVT Raptor, and Limited models.
- Section 12: Charging Systems
- Section 13: Power Distribution
- Section 14: Module Communications for HS-CAN, MS-CAN, and I-CAN with data-bus messages
- Section 20: Starting Systems
- Sections 23-26: Powertrain Controls for 6.2L, 5.0L, 3.5L, and 3.7L engines
- Section 30: Transmission Controls (6R80)
- Section 31: Steering Column Control Module
- Section 34: Transfer Case Control Module
- Section 43: Power Steering Control Module
- Section 130: Audio Control Module (Base, Mid-Level, and Premium Sound)
Number of Pages: 268
